trees

Source Code

You can download the Rmarkdown notebook used to render this article here. To download the file, use the button Download raw file on the upper-right hand of the Code panel.

Overview

The trees dataset focuses on the distribution of the tree species present in Mesoamerica across North and South America. The presence of Mesoamerican trees was obtained from the Tree Biodiversity Network (BIOTREE-NET) dataset (project now defunct). The distribution of these species across the Americas was derived from GBIF. The data represents richness of Mesoamerican trees in the Americas for 3,373 hexagonal grid cells across the Americas, combined with 50 environmental predictor variables from different sources. The dataset was originally compiled for Benito et al. (2013).

Its main features are:

• Americas scope: Hexagonal cells covering longitudes -125.3° to -34.3° and latitudes -34.4° to 49.9°.
• Single response: trees, an integer count of tree species richness per hexagonal cell.
• Rich environmental predictors: 50 predictors spanning 10 categories (climate, soil, vegetation, geography, and more).

We designed it to support regression modelling, multicollinearity filtering, and spatial analysis of tree diversity patterns.

Setup

The following R libraries and example data are required to run this tutorial.

Description

The dataset is an sf data frame with 3373 rows and 53 columns, and 989 cells with NA in the trees response variable (cells where environmental data is valid but no tree species were found in the relevant databases). The first 10 records and all columns but geometry are shown below.

trees |>
  head(n = 10) |>
  dplyr::glimpse()
#> Rows: 10
#> Columns: 53
#> $ cellid                        <int> 1, 2, 3, 4, 5, 6, 7, 8, 9, 10
#> $ trees                         <int> 1, NA, 1, 5, 1, NA, NA, NA, NA, NA
#> $ air_humidity_max              <dbl> 66.72578, 68.97865, 65.92500, 63.75984, …
#> $ air_humidity                  <dbl> 64.19672, 65.28275, 62.97762, 60.19885, …
#> $ air_humidity_min              <dbl> 62.62891, 62.51946, 59.47713, 55.22597, …
#> $ air_humidity_range            <dbl> 3.675112, 5.961699, 5.949539, 8.043704, …
#> $ aridity                       <dbl> 3.034283, 7.000583, 2.228907, 3.352518, …
#> $ cloud_cover_max               <dbl> 51.80775, 59.59544, 49.02710, 53.67749, …
#> $ cloud_cover                   <dbl> 39.38748, 49.43344, 36.08522, 37.64137, …
#> $ cloud_cover_min               <dbl> 23.980626, 37.773336, 18.689770, 14.2178…
#> $ cloud_cover_range             <dbl> 27.21311, 21.36061, 29.83153, 38.95784, …
#> $ evapotranspiration_max        <dbl> 145.8778, 121.9521, 162.0084, 165.8928, …
#> $ evapotranspiration            <dbl> 81.39344, 62.25680, 86.53583, 83.38519, …
#> $ evapotranspiration_min        <dbl> 31.34277, 18.14818, 26.22737, 24.54848, …
#> $ evapotranspiration_range      <dbl> 114.0328, 103.3089, 135.2890, 140.8501, …
#> $ rainfall_seasonality          <dbl> 69.05514, 58.10799, 83.43844, 73.72836, …
#> $ rainfall                      <dbl> 1984.803, 3788.573, 1797.700, 2674.796, …
#> $ rainfall_coldest_quarter      <dbl> 899.4158, 1485.1863, 935.7548, 1274.9368…
#> $ rainfall_driest_month         <dbl> 13.207154, 72.568857, 4.360102, 12.90247…
#> $ rainfall_driest_quarter       <dbl> 74.86140, 287.73483, 34.07716, 87.48721,…
#> $ rainfall_warmest_quarter      <dbl> 74.86140, 314.23001, 34.07716, 87.48721,…
#> $ rainfall_wettest_month        <dbl> 354.6468, 601.3340, 376.6572, 511.7660, …
#> $ rainfall_wettest_quarter      <dbl> 952.3741, 1699.2585, 954.7104, 1328.0056…
#> $ temperature_isothermality     <dbl> 42.31744, 31.10151, 46.19262, 40.70953, …
#> $ temperature_mean_daily_range  <dbl> 4.970194, 4.531185, 7.362851, 7.845559, …
#> $ temperature                   <dbl> 10.965723, 8.226245, 10.837620, 10.12197…
#> $ temperature_range             <dbl> 12.12370, 15.21725, 16.33477, 19.58319, …
#> $ temperature_seasonality       <dbl> 255.8554, 356.1905, 308.2309, 410.3759, …
#> $ temperature_coldest_month_min <dbl> 5.6348733, 1.8606111, 4.1480463, 2.53274…
#> $ temperature_coldest_quarter   <dbl> 8.016393, 4.015278, 7.217357, 5.473721, …
#> $ temperature_driest_quarter    <dbl> 14.54247, 12.75220, 15.08227, 15.84711, …
#> $ temperature_warmest_month_max <dbl> 18.26975, 17.30557, 20.92225, 22.42327, …
#> $ temperature_warmest_quarter   <dbl> 14.54247, 13.03118, 15.08227, 15.84711, …
#> $ temperature_wettest_quarter   <dbl> 8.542474, 4.589159, 7.622423, 5.954469, …
#> $ distance_to_ocean             <dbl> 47.70194, 95.32629, 160.80169, 236.81731…
#> $ elevation                     <dbl> 82.64232, 279.17706, 327.39466, 516.4347…
#> $ latitude                      <dbl> 43.07518, 48.57816, 40.58208, 42.43964, …
#> $ longitude                     <dbl> -124.3935, -124.6602, -124.0775, -124.14…
#> $ soil_clay                     <dbl> 18.97297, 19.41023, 26.68421, 28.00797, …
#> $ soil_nitrogen                 <dbl> 4.081081, 5.990067, 3.774358, 4.297677, …
#> $ soil_organic_carbon           <dbl> 69.37015, 86.66117, 72.22415, 75.67207, …
#> $ soil_ph                       <dbl> 5.242456, 4.839451, 5.537970, 5.388273, …
#> $ soil_sand                     <dbl> 49.89072, 32.86094, 28.39756, 31.97907, …
#> $ soil_silt                     <dbl> 29.78496, 46.36619, 43.56146, 38.65843, …
#> $ soil_temperature_max          <dbl> 20.68563, 19.32484, 23.68939, 24.77120, …
#> $ soil_temperature              <dbl> 10.056886, 7.044211, 11.533294, 10.98734…
#> $ soil_temperature_min          <dbl> 1.9985030, -0.7671579, 2.9644339, 1.4102…
#> $ soil_temperature_range        <dbl> 18.21407, 20.42632, 20.22940, 22.93742, …
#> $ ndvi_max                      <dbl> 0.7350104, 0.8117852, 0.7702507, 0.77888…
#> $ ndvi                          <dbl> 0.6665069, 0.7123055, 0.7063288, 0.71021…
#> $ ndvi_min                      <dbl> 0.5839046, 0.6050872, 0.6405807, 0.62898…
#> $ ndvi_range                    <dbl> 0.1511058, 0.2066980, 0.1296699, 0.14990…
#> $ geometry                      <POLYGON [°]> POLYGON ((-124.8289 42.6689..., POLYGON …

The hexagonal grid cells cover the Americas between approximately 50°N and 35°S. The map below shows the grid coloured by tree richness.

mapview::mapview(
  trees,
  zcol = "trees",
  layer.name = "trees",
  col.regions = viridis::turbo(
    n = 100,
    direction = 1
  ),
  color = NULL,
  at = c(1, 10, 100, 1000, 10000, 20000)
)

Response Variable

The response variable trees (named in the vector trees_response) is an integer count of tree species richness per hexagonal cell, derived from GBIF and BIOTREE-NET occurrence records acquired circa 2013.

summary(trees$trees)
#>    Min. 1st Qu.  Median    Mean 3rd Qu.    Max.     NAs
#>     1.0     5.0    21.0   219.5    89.0 17756.0     989

The dataset includes 50 numeric predictors, named in the vector trees_predictors.

trees |>
  sf::st_drop_geometry() |>
  dplyr::select(
    dplyr::all_of(trees_predictors)
  ) |>
  head(n = 5) |>
  dplyr::glimpse()
#> Rows: 5
#> Columns: 50
#> $ air_humidity_max              <dbl> 66.72578, 68.97865, 65.92500, 63.75984, …
#> $ air_humidity                  <dbl> 64.19672, 65.28275, 62.97762, 60.19885, …
#> $ air_humidity_min              <dbl> 62.62891, 62.51946, 59.47713, 55.22597, …
#> $ air_humidity_range            <dbl> 3.675112, 5.961699, 5.949539, 8.043704, …
#> $ aridity                       <dbl> 3.034283, 7.000583, 2.228907, 3.352518, …
#> $ cloud_cover_max               <dbl> 51.80775, 59.59544, 49.02710, 53.67749, …
#> $ cloud_cover                   <dbl> 39.38748, 49.43344, 36.08522, 37.64137, …
#> $ cloud_cover_min               <dbl> 23.98063, 37.77334, 18.68977, 14.21782, …
#> $ cloud_cover_range             <dbl> 27.21311, 21.36061, 29.83153, 38.95784, …
#> $ evapotranspiration_max        <dbl> 145.8778, 121.9521, 162.0084, 165.8928, …
#> $ evapotranspiration            <dbl> 81.39344, 62.25680, 86.53583, 83.38519, …
#> $ evapotranspiration_min        <dbl> 31.34277, 18.14818, 26.22737, 24.54848, …
#> $ evapotranspiration_range      <dbl> 114.0328, 103.3089, 135.2890, 140.8501, …
#> $ rainfall_seasonality          <dbl> 69.05514, 58.10799, 83.43844, 73.72836, …
#> $ rainfall                      <dbl> 1984.803, 3788.573, 1797.700, 2674.796, …
#> $ rainfall_coldest_quarter      <dbl> 899.4158, 1485.1863, 935.7548, 1274.9368…
#> $ rainfall_driest_month         <dbl> 13.207154, 72.568857, 4.360102, 12.90247…
#> $ rainfall_driest_quarter       <dbl> 74.86140, 287.73483, 34.07716, 87.48721,…
#> $ rainfall_warmest_quarter      <dbl> 74.86140, 314.23001, 34.07716, 87.48721,…
#> $ rainfall_wettest_month        <dbl> 354.6468, 601.3340, 376.6572, 511.7660, …
#> $ rainfall_wettest_quarter      <dbl> 952.3741, 1699.2585, 954.7104, 1328.0056…
#> $ temperature_isothermality     <dbl> 42.31744, 31.10151, 46.19262, 40.70953, …
#> $ temperature_mean_daily_range  <dbl> 4.970194, 4.531185, 7.362851, 7.845559, …
#> $ temperature                   <dbl> 10.965723, 8.226245, 10.837620, 10.12197…
#> $ temperature_range             <dbl> 12.12370, 15.21725, 16.33477, 19.58319, …
#> $ temperature_seasonality       <dbl> 255.8554, 356.1905, 308.2309, 410.3759, …
#> $ temperature_coldest_month_min <dbl> 5.634873, 1.860611, 4.148046, 2.532743, …
#> $ temperature_coldest_quarter   <dbl> 8.016393, 4.015278, 7.217357, 5.473721, …
#> $ temperature_driest_quarter    <dbl> 14.54247, 12.75220, 15.08227, 15.84711, …
#> $ temperature_warmest_month_max <dbl> 18.26975, 17.30557, 20.92225, 22.42327, …
#> $ temperature_warmest_quarter   <dbl> 14.54247, 13.03118, 15.08227, 15.84711, …
#> $ temperature_wettest_quarter   <dbl> 8.542474, 4.589159, 7.622423, 5.954469, …
#> $ distance_to_ocean             <dbl> 47.70194, 95.32629, 160.80169, 236.81731…
#> $ elevation                     <dbl> 82.64232, 279.17706, 327.39466, 516.4347…
#> $ latitude                      <dbl> 43.07518, 48.57816, 40.58208, 42.43964, …
#> $ longitude                     <dbl> -124.3935, -124.6602, -124.0775, -124.14…
#> $ soil_clay                     <dbl> 18.97297, 19.41023, 26.68421, 28.00797, …
#> $ soil_nitrogen                 <dbl> 4.081081, 5.990067, 3.774358, 4.297677, …
#> $ soil_organic_carbon           <dbl> 69.37015, 86.66117, 72.22415, 75.67207, …
#> $ soil_ph                       <dbl> 5.242456, 4.839451, 5.537970, 5.388273, …
#> $ soil_sand                     <dbl> 49.89072, 32.86094, 28.39756, 31.97907, …
#> $ soil_silt                     <dbl> 29.78496, 46.36619, 43.56146, 38.65843, …
#> $ soil_temperature_max          <dbl> 20.68563, 19.32484, 23.68939, 24.77120, …
#> $ soil_temperature              <dbl> 10.056886, 7.044211, 11.533294, 10.98734…
#> $ soil_temperature_min          <dbl> 1.9985030, -0.7671579, 2.9644339, 1.4102…
#> $ soil_temperature_range        <dbl> 18.21407, 20.42632, 20.22940, 22.93742, …
#> $ ndvi_max                      <dbl> 0.7350104, 0.8117852, 0.7702507, 0.77888…
#> $ ndvi                          <dbl> 0.6665069, 0.7123055, 0.7063288, 0.71021…
#> $ ndvi_min                      <dbl> 0.5839046, 0.6050872, 0.6405807, 0.62898…
#> $ ndvi_range                    <dbl> 0.1511058, 0.2066980, 0.1296699, 0.14990…

Raw Data

You can download the raw presence data with trees_extra().

trees_presence <- spatialData::trees_extra()
#> spatialData::trees_extra(): Downloading file 'trees_presence.gpkg'.
head(trees_presence)
#> Simple feature collection with 6 features and 2 fields
#> Geometry type: POINT
#> Dimension:     XY
#> Bounding box:  xmin: -105.1558 ymin: 19.99083 xmax: -105.1143 ymax: 20.03075
#> Geodetic CRS:  WGS 84
#>                            species      source                       geom
#> 1    Dodonaea_viscosa_angustifolia BIOTREE.net POINT (-105.1558 20.03075)
#> 2 Trichilia_quadrijuga_cinerascens BIOTREE.net POINT (-105.1558 20.03075)
#> 3        Myrsine_coriacea_coriacea BIOTREE.net POINT (-105.1558 20.03075)
#> 4        Myrsine_coriacea_coriacea BIOTREE.net POINT (-105.1431 20.00116)
#> 5        Myrsine_coriacea_coriacea BIOTREE.net POINT (-105.1213 19.99217)
#> 6        Myrsine_coriacea_coriacea BIOTREE.net POINT (-105.1143 19.99083)

Example Usage

In this example we use trees to assess how climate extremes drive tree richness across the Americas.

• Log Transformation: to facilitate the visualization of model results.
• Variable Selection: multicollinearity analysis of the selected environmental variables.
• Conditional Inference Trees: fits a permutation-based tree model to explain tree richness patterns.
• Prediction Map: maps the model predictions back to the hexagonal grid.

Log Transformation

Before proceeding with the variable selection, we log-transform the response variable trees into a new column log_trees to facilitate the visualization of model results.

Tree species richness spans several orders of magnitude across the Americas, producing a strongly skewed distribution that makes terminal node summaries in the conditional inference tree difficult to read. While log-transforming count data is no longer recommended for linear models, it has no meaningful effect on split selection in ctree(), which relies on rank-based permutation tests that are invariant to monotone transformations of the response.

trees <- trees |>
  dplyr::mutate(
    log_trees = log(trees)
  )

Variable Selection

Now let’s identify which extreme-climate predictors are worth keeping.

The predictors indicating climate extreme values are identified with the suffixes _min and _max in trees_predictors, with the exception of rainfall, where rainfall_driest_month and rainfall_wettest_month represent the monthly minimum and maximum respectively.

The code below selects these predictors, and excludes ndvi_*.

trees_extremes <- grep(
  pattern = "^(?!.*ndvi).*(min|max|driest_month|wettest_month)",
  x = colnames(trees),
  perl = TRUE,
  value = TRUE
)

trees_extremes
#>  [1] "air_humidity_max"              "air_humidity_min"
#>  [3] "cloud_cover_max"               "cloud_cover_min"
#>  [5] "evapotranspiration_max"        "evapotranspiration_min"
#>  [7] "rainfall_driest_month"         "rainfall_wettest_month"
#>  [9] "temperature_coldest_month_min" "temperature_warmest_month_max"
#> [11] "soil_temperature_max"          "soil_temperature_min"

Once the candidate pool of variables is selected, we use collinear::collinear() to select a non-redundant subset by prioritizing predictors by their predictive power for the response.

trees_selection <- collinear::collinear(
  df = trees,
  responses = "log_trees",
  predictors = trees_extremes,
  f = collinear::f_numeric_rf,
  max_vif = 2.5,
  quiet = TRUE
)

The selected predictors for trees are:

trees_selection$log_trees$selection
#> [1] "air_humidity_min"       "rainfall_wettest_month" "cloud_cover_max"
#> [4] "soil_temperature_max"
#> attr(,"validated")
#> [1] TRUE

The function also returns a linear formula ready for use, and a clean dataframe ready for analysis.

trees_selection$log_trees$formulas$linear
#> log_trees ~ air_humidity_min + rainfall_wettest_month + cloud_cover_max +
#>     soil_temperature_max
#> <environment: 0x556166f44d00>

Conditional Inference Tree

With a clean predictor set, we can fit an interpretable regression tree.

A conditional inference tree provides an interpretable summary of how the selected predictors interact to explain tree species richness. The model is fitted with partykit::ctree(), which uses permutation tests to select splits without overfitting bias.

trees_model <- partykit::ctree(
  formula = trees_selection$log_trees$formulas$linear,
  data = trees |>
    sf::st_drop_geometry() |>
    na.omit(),
  control = partykit::ctree_control(
    minbucket = 100 #minimum cases in a terminal leaf
  )
)

The conditional inference tree below shows the sequence of environmental thresholds that best explain differences in tree species richness. Each internal node shows the splitting variable, threshold, and p-value of the permutation test; each terminal node (leaf) shows a boxplot with the richness values of the samples it contains.

plot(x = trees_model)

Interpretation examples

The results of conditional inference trees are easy to interpret when the model has a reasonable number of terminal nodes. Below I discuss the climate conditions leading to the highest and lowest predicted richness according to the model.

Node 15, at the right, has the highest predicted median richness. The relevant climate thresholds leading to maximum tree richness are:

• Minimum air humidity higher than 53%.
• Rainfall of the wettest month higher than 115mm.
• Rainfall of the wettest month higher than 451mm.

Node 7, third from the left, shows the lowest predicted tree richness, and features these climate thresholds:

• Minimum air humidity smaller than 53%.
• Rainfall of the wettest month higher than 104mm.
• Maximum cloud cover higher than 36%.

Prediction Map

Let’s map the model predictions back onto the hexagonal grid.

Assigning predictions back to the grid reveals how well this simple model captures geographic variation in richness. Notice that the prediction of partykit::ctree() can be expressed as a quantile of the cases within each terminal node. Below we show the prediction for the quantile 0.75.

trees$predicted <- predict(
  object = trees_model,
  newdata = sf::st_drop_geometry(trees),
  type = "quantile",
  at = 0.75 #prediction at quantile 0.75
) |>
  exp() |> #convert log(trees) to natural range
  as.integer() |>
  as.factor()

mapview::mapview(
  trees,
  zcol = "predicted",
  layer.name = "Predicted richness",
    col.regions = viridis::turbo(
    n = 8,
    direction = 1
  ),
  color = NULL
)

Conclusion

This example walked through extreme-climate predictor selection, a conditional inference tree, and spatial prediction onto a hexagonal grid, a simple but interpretable pipeline for exploring tree richness gradients.

References

Benito, B.M., Cayuela, L., & Albuquerque, F.S. (2013). The impact of modelling choices in the predictive performance of richness maps derived from species-distribution models: Guidelines to build better diversity models. Methods in Ecology and Evolution, 4(4), 327–335. https://doi.org/10.1111/2041-210X.12022
